LM-EX11 |
|
| LINK-MI LM-EX11 50m HDMI Extender Over Single Cat5e/6 Cable |
| |
Introduction:
1.Each set includes one transmitter and one receiver.2.Use single UTP LAN cable（Cat5E/6)to substitute HDMI cable to achieve long distance transmission, the UTP Cable follows the standard of IEEE-568B.3.Transmission distance extend up to 50 meters under 1080P .4.Supports Deep Color up to 36 bits.5.Supports lossless compressed digital audio: Dolby True-HD, DTS-HD Master Audio.6.Transmit Digital Audio and Video over the CAT6 / CAT5e cable with zero signal loss. 7.Data transfer speed 6.75 Gbps. 8.DC 5V power supply.9.EDID copy function. |
|
|
| |
|
|
|

Specification
|
Brand |
LINK-MI |
|
Model No. |
LM-EX11 |
|
Material |
Metal |
|
Color |
Black |
|
Interface |
HDMI |
|
Application |
Extend HDMI Signal up to 50m over cat5e/6 cable |
|
Operating Temperature Range |
-5 to +35 Degree Celsius ( +23 to +95 Degree Fahrenheit ) |
|
Operating Humidity Range |
5 to 90%RH ( No Condensation ) |
|
Input Video Signal |
0.5-1.0 Volts P-P |
|
Input DDC Signal |
5 Volts P-P ( TTL ) |
|
Video Format |
DTV/HDTV: 480i/576i/480p/576p/720p/1080i/1080p 3D Video |
|
Video Output |
HDMI +HDCP |
|
Audio Format |
DTS-HD Master Audio, Dolby True-HD etc. |
|
Transmission Distance |
1080p 8-bit 50m( Max. ) Over Single Cat5e/6/24AWG/Solid |
|
Power Consumption |
5 Watts ( Max. ) |
|
Dimension ( L*W*H ) |
83*48*25mm |
|
Net Weight |
250g ( Pair ) |
Packing Contents
1. Main Unit. HDMI Extender Transmitter & Receiver
2. 2pcs DC 5V 1A Power Adapter
3. Operating Instructions
|
 |
|
|
|
|
